ROLLER PAN MIXER ( CEW 19 )

(4955 customer reviews)

Category:

Description

ROLLER PAN MIXER .

Of 1500mm 0r 1600mm diameter Height 508mm fabricated with structural

Mild steel with replaceable inner lining fitted & By Heavy Hand Roller & hand

Faced scrapers for Material mixing with 5 HP or 7.5 HP motor, oil filled

Reduction gear Box for feeding hoper with a capacity to mix 400 to 600 kg.

Of raw-Materials.

SPECIFICATION :-

  1. ELECTRIC MOTOR    :5 or 7.5 HP (Crompton, ABB, Shreeji)
  2. MIXING CAPACITY    :- 400 to 600 Kg. Batch approx each pan mixture
  3. MATERIAL               :- Material Feeding & Discharge (Manual / Automatic)
  4. MIXER ARMS               :-  Heavy Roller 2 nos &  Arms for Material Mixing)
  5. Oil Capacity             :- 15 ltr. (90 no Gear Oil)
  6. Material Use :- Bottom Plate 10mm & Side Wall Plate 6mm+

3mm (10inch) Replaceable
